Cutting Machines
Engineered for precision and durability, our cutting machines are designed to tackle tough materials with ease. Whether for high-volume production or custom applications, they ensure clean edges, consistent quality, and optimized cycle times—making them a smart choice for modern manufacturing lines.
01
Corrugated Tube Cutting Machine
Description:
A Corrugated Tube Cutting Machine is a specialized piece of equipment designed for the precise and efficient cutting of corrugated tubing, commonly used in wiring harnesses, cable management systems, and protective conduits
Key points:
• Machine type : Semi-Automatic
• Cutting Mechanism : Pneumatic Based
• Material handling : Manually
• Max cut length : Up to 8 meters
• Tube size : Ø6mm – Ø30mm
• Features : Precision cutting, Fixture changeover, Measuring slider, De- coiler, Storage for verifying and placing cut pieces, etc.
02
Rubber Strip Cutting Machine
Description:
The automatic rubber shearing machine is used to cut various rubber products, plastic materials, and other non-metallic materials with certain hardness. The structure is simple, the degree of automation is high, the operation is simple, the noise is low, and it has a good safety protection device. The feeding stroke is adjustable, and the weight of the obtained rubber material is accurate
Key points:
• Machine type : Semi-Automatic
• Cutting Mechanism : Motor with camshaft.
• Maximum cutting width : 600mm or customized
• Maximum Sheet Thickness : 12 mm
• Maximum Feeding Stroke : 1mm-70mm
• Material Feeding : Input through conveyor
• Features : Precision cutting, Fixture changeover, Measuring slider, Adjustable cut length, Automatic Feeding etc
03
Gum Rework Unit
Description:
The Gum Rework Conveyor is a specialized industrial machine engineered for efficient handling and precise cutting of raw rubber sheets. Designed to streamline the rework process, this robust system automates the transformation of bulk rubber sheets into uniform strips, tailored to your specific width requirements
Key points:
• Machine type : Semi-Automatic
• Cutting Mechanism : Rotary Cutter.
• Maximum cutting width : 600mm or customized
• Maximum Sheet Thickness : 25 mm
• Maximum Feeding Stroke : 1mm-70mm
• Material Feeding : Input through conveyor
• Features : Precision cutting, Fixture changeover, Measuring slider, Adjustable cut length, Automatic Feeding etc.
04
Wire Mesh Cutting Machine
Description:
The Wire Mesh Cutting Machine is a compact yet powerful solution engineered for precision cutting of polythene wire mesh. Designed with efficiency and versatility in mind, this machine stands out in its segment for delivering clean, consistent cuts with a minimal footprint.
Key points:
• Machine type : Fully-Automatic
• Cutting Mechanism : Pneumatic-based blade with heater.
• Maximum cutting width : Customized
• Maximum Mesh width :150 mm
• Maximum Feeding Stroke : 1mm-20mm
• Material Feeding : Input through conveyor
• Features : Precision cutting, Fixture changeover, Measuring slider, Adjustable cut length, Automatic Feeding, etc
